6x24 Narrow Dock Platform Plans | DIY Canoe & Swim Dock - Table Rock Lake Design
$52 — instant digital download (PDF + DWG plan set with material list).
This 6x24 foot dock is perfect for paddlers, swimmers, or compact boat access. The extended length makes it ideal for deeper water or sloped lakefronts - with enough room to lounge, fish, or park. 24 ft length - generous room for loading/unloading 6 ft width - perfect for single-sided tie-up or center access Wood piling foundation - durable and code-aligned Ideal for Lakefront properties Ideal for lakefront properties, riverbanks, or calm bays, this dock plan is optimized for DIYers or contractors seeking a professional layout to submit for permitting and construction. Plan Details: Total Deck Area: 6 ft x 24 ft Material specifications included (timber frame, pilings) 2D Plan Set (PDF): layout, framing, post spacing, and notes Optional CAD add-on available for engineers/contractors What's Included in the PDF Plan Set (6 Sheets Total): A0.0 - Cover Sheet (notes, project info, index) A1.0 - Boat Deck Plan (top view with dimensions) A2.0 - Elevations (side views showing height & roof pitch) A3.0 - 3D View (realistic perspective render) S1.0 - Deck Framing + Sheeting Plan M1.0 - Materials Sheet (suggested lumber sizes, quantities, fasteners, and notes) Ideal For: Lake homes,…
What's included
- Instant download
- PDF files
- Build plans
- Project details
Specs
| Size | 6x24 ft |
|---|---|
| Type | Boat Dock Plan |
| Format |
