Austin Air 12x16 Pergola Plan - Wall-Mounted Patio Cover PDF - Modern Roof-Attached Shade - Easy DIY Outdoor Living Kit
$46 — instant digital download (PDF + DWG plan set with material list).
What it costs to build
Based on the plan's full material list: estimated DIY material cost $2,529; typical contractor estimate $5,279 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.
Meet the Austin Air 12x16 Roof-Mounted Pergola Plan - a sleek, wall-attached patio cover designed for effortless DIY builds. Whether you're shading a grilling station, creating a cozy outdoor dining space, or extending your home's footprint, this roof-mounted design is functional, stylish, and code-friendly. Developed by the architectural experts at Bamboo Designs, this 12x16 pergola plan maximizes space while minimizing materials - perfect for Austin's sunny climate and creative homeowners ready to elevate their backyard with confidence. What's Included: Full Drawing Set (PDF + DWG) Roof Plan + Framing Layout Roof-Mount Connection Details Elevations + Footing Plan Material List Included Printable on 24"x36" or letter-size sheets Designed to meet IBC/IRC 2024 Guidelines Dimensions: Size: 12 ft x 16 ft Structure Type: Roof Mounted (Metal Hardware) Posts: 3 front support posts Height: Approx. 10-14 ft (adjustable) Whether you're sipping coffee in the morning or entertaining under string lights, this pergola offers comfort, character, and style-all while boosting your home's value. Features: Built for small patios, BBQ stations, or full outdoor lounges Clean, modern profile with…
What's included
- Instant download
- PDF + DWG files
- Build plans
- Material list
Specs
| Size | 12x16 ft |
|---|---|
| Type | Pergola Plan |
| Features | Pergola |
| Format | PDF + DWG |
