Charlotte Classic Pergola - 12x12 DIY Wood Pergola Plans - Patio Shade Structure Blueprint - Instant PDF Download

$48 — instant digital download (PDF + DWG plan set with material list).

What it costs to build

Based on the plan's full material list: estimated DIY material cost $3,452; typical contractor estimate $7,206 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.

Charlotte Classic Pergola - 12x12 DIY Wood Pergola Plans - Patio Shade Structure Blueprint - Instant PDF Download Elevate your outdoor living space with timeless design and DIY simplicity. The Charlotte Classic Pergola brings structure, shade, and style to any backyard, garden, or poolside patio. With a clean 12'x12' footprint and builder-friendly layout, this plan is ideal for homeowners, contractors, and weekend warriors alike. What's Included: Construction Drawing Set: Foundation Plan Roof Plan Elevations Connection Details Complete Material List PDF + DWG Files Included Design Guidelines per IBC/IRC 2024 Standards Pergola Dimensions: Size: 12 feet x 12 feet Height: Approx. 11 feet to top Foundation: 4 footings (12" diameter x 24" deep, no rebar required) Materials Needed: 4x 6x6 Southern Pine Posts (~11'-3") 2x8 Beams & Rafters 2x4 Battens spaced @ 16" O.C. 3/8" anchor bolts, washers, and nuts 10D nails Full cut list and material breakdown included in the PDF Key Features: Designed to withstand up to 140 MPH wind loads Simple, strong footing design (no rebar) Perfect for DIY or pro installation Drawings formatted for print (24"x36" or standard paper) Please Note: Digital…

What's included

Instant download
PDF + DWG files
Build plans
Material list

Specs

Size	12x12 ft
Type	Pergola Plan
Features	Pergola
Format	PDF + DWG
