Los Angeles Luxe Pergola - 16x20 Modern Outdoor Pergola Plan - Luxury Backyard Shade Structure - PDF DIY Set
$27 — instant digital download (PDF + DWG plan set with material list).
What it costs to build
Based on the plan's full material list: estimated DIY material cost $2,785; typical contractor estimate $5,813 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.
Minimal lines. Maximum impact. The Los Angeles Luxe is a 16x20 modern pergola with a clean, architectural profile. Ideal for luxury outdoor spaces, it's designed for long lines, low clutter, and high-style impact. What's Included: Complete Construction Drawing Set Foundation Plan Roof Layout Elevations & Connection Details Detailed Material List Design guidelines aligned with IBC/IRC 2024 PDF and DWG files included for print or customization Pergola Dimensions: Size: 16' x 20' Built for shade, airflow, and easy drainage Simple, bolt-down construction Materials Used: Pressure-Treated Posts Southern Pine Beams, Battens and Rafters Anchor bolts, washers, and 10D nails All quantities and cut lengths listed in the download Key Features: Built to handle 130+ MPH wind loads Clean, modern profile for updated outdoor aesthetics Easy-to-read plans for confident DIY execution Formatted for 24x36 prints or standard letter size Please Note: Digital download only (PDF + DWG) Not stamped - consult local professionals for permit use Buyer responsible for local compliance Perfect For: Backyard patio cover Outdoor kitchen or lounge Poolside retreat Coastal or desert climates Florida backyards…
What's included
- Instant download
- PDF + DWG files
- Build plans
- Material list
Specs
| Size | 16x20 ft |
|---|---|
| Type | Pergola Plan |
| Features | Pergola |
| Format | PDF + DWG |
