Miami Lean-To Pergola Plan - 12x16 Modern Patio Cover - Wall-Mounted DIY Shade Structure - PDF Download
$33 — instant digital download (PDF + DWG plan set with material list).
What it costs to build
Based on the plan's full material list: estimated DIY material cost $4,175; typical contractor estimate $8,715 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.
Maximize your outdoor space with clean, functional design. The Bamboo Designs Miami Lean-To Pergola (12x16) attaches directly to your exterior wall, creating a seamless, covered patio area perfect for relaxing, dining, or entertaining. Ideal for homes with limited yard depth or where you want a more integrated architectural look. What's Included: Detailed Architectural Drawing Set (PDF + DWG) Foundation Layout Roof Framing Plan Elevation Views Wall-Mounted Connection Details Complete Material List Designed to current IBC/IRC 2024 standards Drawings formatted for print (24x36 or letter) Dimensions: Size: 16 ft wide x 12 ft deep Height: Approx. 9-10 ft (customizable in plan) Mount Type: Lean-to wall mount with 3 front posts Footings: 12" dia. x 24" deep concrete piers (x3) Features: Clean, modern style with simple wall-to-post connection Perfect for patio extensions, side yards, or narrow lots Designed with Southern Pine framing Wind-rated for up to 130 MPH (with anchoring) Please Note: This is a digital product only - no physical materials included Plans are not engineer-stamped; consult your local pro for permitting if needed Designed for DIY builders and contractors Ideal For:…
What's included
- Instant download
- PDF + DWG files
- Build plans
- Material list
Specs
| Size | 12x16 ft |
|---|---|
| Type | Pergola Plan |
| Features | Pergola |
| Format | PDF + DWG |
