Orlando Oasis Pergola - 14x20 Large Backyard Pergola Design - DIY Shade Cover Plans (PDF) - Instant Download

$32 — instant digital download (PDF + DWG plan set with material list).

What it costs to build

Based on the plan's full material list: estimated DIY material cost $5,319; typical contractor estimate $11,102 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.

Orlando Oasis Pergola - 14x20 Large Backyard Pergola Design - DIY Shade Cover Plans (PDF) - Instant Download Create your own tropical retreat. The Orlando Oasis is a 14x20 layout made for larger patios and sunny climates. A go-to structure for pool decks, BBQ areas, or garden lounges, this design pairs southern style with functionality. What's Included: Complete Construction Drawing Set Foundation Plan Roof Layout Elevations & Connection Details Detailed Material List Design guidelines aligned with IBC/IRC 2024 PDF and DWG files included for print or customization Pergola Dimensions: Size: 14' x 20' Built for shade, airflow, and easy drainage Simple, bolt-down construction Materials Used: Pressure-Treated Posts Southern Pine Beams, Battens and Rafters Anchor bolts, washers, and 10D nails All quantities and cut lengths listed in the download Key Features: Built to handle 130+ MPH wind loads Clean, modern profile for updated outdoor aesthetics Easy-to-read plans for confident DIY execution Formatted for 24x36 prints or standard letter size Please Note: Digital download only (PDF + DWG) Not stamped - consult local professionals for permit use Buyer responsible for local compliance…

What's included

Instant download
PDF + DWG files
Build plans
Material list

Specs

Size	14x20 ft
Type	Pergola Plan
Features	Pergola
Format	PDF + DWG
