Santa Fe Pergola - 16x20 Modern Wood Pergola Plans - DIY Outdoor Shade Structure - PDF Blueprint Download - Lean to Wall Patio

$41 — instant digital download (PDF + DWG plan set with material list).

What it costs to build

Based on the plan's full material list: estimated DIY material cost $1,606; typical contractor estimate $3,352 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.

Santa Fe Pergola - 16x20 Modern Wood Pergola Plans - DIY Outdoor Shade Structure - PDF Blueprint Download Minimal footprint. Maximum vibe. The Santa Fe Lanai - 16x20 patio is designed for smaller patios, apartment courtyards, and shaded nooks. Perfect for damp-weather cities like Santa Fe, this design lets you build smart shelter without dominating your space. What's Included: Full Drawing Set (PDF + DWG) Roof Plan + Framing Layout Wall-Mount Connection Details Elevations + Footing Plan Material List Included Printable on 24"x36" or letter-size sheets Designed to meet IBC/IRC 2024 Guidelines Dimensions: Size: 16 ft x 20 ft Structure Type: Lean-to (attached to wall) Posts: 3 front support posts Height: Approx. 9-10 ft (adjustable) Features: Built for small patios, BBQ stations, or full outdoor lounges Clean, modern profile with wide span rafters DIY-friendly plans or contractor-ready details Wind-rated up to 130 MPH with anchoring Please Note: Digital product only - no physical materials are shipped Not engineer-stamped - consult local pro for permit-ready adaptation Designed for planning and DIY construction Perfect For: Covered outdoor kitchens or lounges Firepit zones or…

What's included

Instant download
PDF + DWG files
Build plans
Material list

Specs

Size	16x20 ft
Type	Pergola Plan
Features	Pergola
Format	PDF + DWG
