Sonoma Sideyard Pergola - 8x18 Overhang Shade Structure - One-Sided Modern DIY Pergola Plans - PDF Blueprint
$44 — instant digital download (PDF + DWG plan set with material list).
Sonoma Sideyard Pergola - 8x18 Overhang Shade Structure - One-Sided Modern DIY Pergola Plans - PDF Blueprint Wine country vibes, built into your backyard. The Sonoma Sideyard Pergola is a sleek 8x18 one-sided pergola plan, perfect for narrow patios, outdoor kitchens, or tucked-away lounge spaces. Designed with a modern overhang and only two rear posts, it keeps the front open while offering bold architectural shade - no clutter, just clean coverage. What's Included: Full Drawing Set (PDF + DWG) Roof Plan + Framing Layout Connection Details Elevations + Footing Plan Material List Included Printable on 24"x36" or letter-size sheets Designed to meet IBC/IRC 2024 Guidelines Dimensions: Size: 8 ft x 18ft Support: 3-post asymmetrical + modern design (rear-supported) Height: Approx. 9-10 ft (adjustable) Features: Built for small patios, BBQ stations, or full outdoor lounges Clean, modern profile with wide span rafters DIY-friendly plans or contractor-ready details Wind-rated up to 130 MPH with anchoring Please Note: Digital product only - no physical materials are shipped Not engineer-stamped - consult local pro for permit-ready adaptation Designed for planning and DIY construction…
What's included
- Instant download
- PDF + DWG files
- Build plans
- Material list
Specs
| Size | 8x18 ft |
|---|---|
| Type | Pergola Plan |
| Features | Pergola |
| Format | PDF + DWG |
