Stargate Pergola - 20x30 Lean-To Wall Pergola Plans - Massive Outdoor Living Shade - PDF DIY Patio Cover Blueprint
$33 — instant digital download (PDF + DWG plan set with material list).
What it costs to build
Based on the plan's full material list: estimated DIY material cost $2,290; typical contractor estimate $4,779 (materials + labor + overhead). See the live material cost calculator for the line-by-line breakdown.
Stargate Pergola - 20x30 Lean-To Wall Pergola Plans - Massive Outdoor Living Shade - PDF DIY Patio Cover Blueprint Enter a new dimension of backyard living. The Stargate Pergola is our largest lean-to wall-mounted pergola yet - a 20x30 architectural shade structure designed to cover full-length outdoor kitchens, lounge zones, and dining spaces with confidence and style. What's Included: Full Construction Plan Set (PDF + DWG) Roof framing layout + wall connection detail Foundation / post layout Elevations & material list Printable PDF (24x36 or letter size) Designed to current IBC/IRC 2024 codes Dimensions: Size: 30 ft wide x 20 ft deep Mount Type: Lean-to (attaches to existing wall) Support: 3 front posts + beam layout Height: Adjustable, ~9-10 ft typical Features: Massive coverage for multi-zone patios Perfect for outdoor kitchens, lounge areas, or fire pit zones Clean rafters, exposed framing, and modern slope Wind-rated up to 130 MPH Notes: Digital plans only - no physical product or materials included Not engineer-stamped. Consult a local pro for permit adaptation Designed for DIY or contractor installation Best For: Full-width patios Outdoor entertaining zones Large estate…
What's included
- Instant download
- PDF + DWG files
- Build plans
- Material list
Specs
| Size | 20x30 ft |
|---|---|
| Type | Pergola Plan |
| Features | Pergola |
| Format | PDF + DWG |
